Compare Quadro GPUs

BOARD FEATURES	Quadro GP100	Quadro P6000	Quadro P5000	Quadro P4000	Quadro P2000	Quadro P1000	Quadro P600	Quadro P400
Memory Size	16GB HBM2	24GB GDDR5X	16GB GDDR5X	8GB GDDR5	5GB GDDR5	4GB GDDR5	2GB GDDR5	2GB GDDR5
Memory Interface	4096-bit	384-bit	256-bit	256-bit	160-bit	128-bit	128-bit	64-bit
Memory Bandwidth	Up to 717 GBps	Up to 432 GBps	Up to 288 GBps	Up to 243 GBps	Up to 140 GBps	Up to 80 GBps	Up to 64 GBps	Up to 32 GBps
NVIDIA® CUDA™ Parallel Processor Cores	3584	3840	2560	1792	1024	640	384	256
Max Power Consumption	235W	250W	180W	105W	75W	47W	40W	30W
Power Connector	1 x 8-pin	1 x 8-pin	1 x 8-pin	1 x 6-pin
Number of slots	2	2	2	1	1	1	1	1
# Simultaneous Displays²	4	4	4	4	4	4	4	4
Display Connectors	DVI-D DP DP DP DP 3-pin Stereo¹	DVI-D DP DP DP DP 3-pin Stereo¹	DVI-D DP DP DP DP 3-pin Stereo¹	DP DP DP DP 3-pin Stereo¹	DP DP DP DP	mDP mDP mDP mDP	mDP mDP mDP mDP	mDP mDP mDP
NVIDIA® VR Ready	*
ECC (Error Correcting Code)	3	4	4
OpenGL	4.57	4.57	4.57	4.57	4.57	4.57	4.57	4.57
Vulkan	1.07	1.07	1.07	1.07	1.07	1.07	1.07	1.07
Shader Model	5.1	5.1	5.1	5.1	5.1	5.1	5.1	5.1
DirectX	128	128	128	128	128	128	128	128
NVIDIA 3D Vision® Pro
NVIDIA® Mosaic Technology
Multi-Display Synchronization	Quadro Sync II	Quadro Sync II	Quadro Sync II	Quadro Sync II
NVIDIA SLI® Support5
NVIDIA® nView® Desktop Management Technology
High-Performance Video I/O6

* The GP100 is VR Ready, but does not support simultaneous multiprojection or any software features that require this functionality.
1 Optional
2 Directly attached displays
3 On both GPU Cache and on-board DRAM
4 On on-board DRAM
5 On SLI Certified Platforms
6 Supported via GPUDirect for Video enabled 3rd party I/O boards
7 Product is based on a published Khronos Specification, and is expected to pass the Khronos Conformance Testing Process when available. Current conformance status can be found at www.khronos.org/conformance
8 GPU supports DX 12 API, Hardware Feature Level 12_1

BOARD FEATURES	Quadro M6000 24GB	Quadro M5000	Quadro M4000	Quadro M2000	Quadro K1200	Quadro K620	Quadro K420
Memory Size	24GB GDDR5	8GB GDDR5	8GB GDDR5	4GB GDDR5	4GB GDDR5	2GB DDR3	1 GB/2 GB DDR3
Memory Interface	384-bit	256-bit	256-bit	128-bit	128-bit	128-bit	128-bit
Memory Bandwidth	Up to 317 GBps	Up to 211 GBps	Up to 192 GBps	Up to 106 GBps	Up to 80 GBps	Up to 29 GBps	Up to 29 GBps
NVIDIA® CUDA™ Parallel Processor Cores	3072	2048	1664	768	512	384	192
Max Power Consumption	250W	150W	120W	75W	45W	41W	41W
Power Connector	1 x 8-pin	1 x 6-pin	1 x 6-pin
Number of slots	2	2	1	1	1	1	1
# Simultaneous Displays2	4	4	4	4	4	4	4
Display Connectors	DVI-I DP DP DP DP 3-pin Stereo1	DVI-I DP DP DP DP 3-pin Stereo1	DP DP DP DP 3-pin Stereo1	DP DP DP DP	mDP mDP mDP mDP	DVI-I DP	DVI-I DP
ECC (Error Correcting Code)	4	4
OpenGL	4.57	4.57	4.57	4.57	4.57	4.57	4.57
Vulkan	1.07	1.07	1.07	1.07	1.07	1.07	1.07
Shader Model	5	5	5	5	5	5	5
DirectX	129	129	129	128	128	128	128
NVIDIA 3D Vision®Pro
NVIDIA® Mosaic Technology
Multi-Display Synchronization	Quadro Sync	Quadro Sync	Quadro Sync
NVIDIA SLI® Support5
NVIDIA® nView® Desktop Management Technology
High-Performance Video I/O6

1 Optional
2 Includes directly attached displays and displays connected through DisplayPort 1.2 hubs
3 On both GPU Cache and on-board DRAM
4 On on-board DRAM
5 On SLI Certified Platforms
6 Supported via GPUDirect for Video enabled 3rd party I/O boards
7 Product is based on a published Khronos Specification, and is expected to pass the Khronos Conformance Testing Process when available. Current conformance status can be found at www.khronos.org/conformance
8 GPU supports DX 12 API, Hardware Feature Level 11_0
9 GPU supports DX 12 API, Hardware Feature Level 12_1
